Atlas Copco GA 55VSD+ to GA 110VSD+ Air Compressors

Categoria Atlas Copco air compressor

Ulteriori informazioni

Modello	GA55VSD+, GA75VSD+, GA75VSD++, GA90VSD+, GA110 VSD+
Working Pressure	4-12.5 sbarra(e), 58-181psig
Capacity FAD	26-348 I/s, 1.45-20.85 m³/min, 51-736 cfm
Installed Motor Power	55-110 kW, 75-150 hp
Noise level	67-76 dB(A)
Weight	900-1222 KG
Price	USD 19,300-USD 28,500

GA55VSD+, GA75VSD+, GA75VSD++, GA90VSD+, GA110VSD+ Air Compressor Parameters

Modello	Working Pressure		Capacity FAD*			Installed Motor Power		Noise level**	Weight	Full performance model weight	Outlet Size
Modello	sbarra(e)	psig	I/s	m³/min	cfm	kW	hp	dB(A)	kg	kg	Outlet Size
GA 55VSD+	4	58	26-189	1.53-11.33	54-400	55	75	67	900	1100	G2″F
	7	102	26-188	1.53-11.28	54-399	55	75	67	900	1100
	9.5	138	26-166	1.55-9.97	55-352	55	75	67	900	1100
	12.5	181	40-140	2.42-8.40	85-297	55	75	67	900	1100
GA 75VSD+	4	58	26-226	1.53-13.58	54-480	75	100	70	900	1100	G2″F
	7	102	26-224	1.60-13.45	52-465	75	100	70	900	1100
	9.5	138	24-193	1.45-11.60	51-410	75	100	70	900	1100
	12.5	181	39-162	2.35-9.73	83-343	75	100	70	900	1100
GA 75VSD++	4	58	47-269	2.83-16.12	100-569	75	100	73	1207	1496	G21/2″F
	7	102	48-269	2.87-16.02	101-565	75	100	73	1207	1496
	9.5	138	58-235	3.50-14.12	124-498	75	100	73	1207	1496
	12.5	181	70-194	4.20-11.65	149-411	75	100	73	1207	1496
GA 90VSD+	4	58	48-311	2.83-18.68	102-660	90	125	74	1213	1503	G21/2″F
	7	102	49-306	2.93-18.35	104-648	90	125	74	1213	1503
	9.5	138	60-269	3.58-16.15	127-570	90	125	74	1213	1503
	12.5	181	71-218	4.25-13.07	150-461	90	125	74	1213	1503
GA110 VSD+	4	58	47-348	2.83-20.85	100-736	110	150	76	1222	1537	G21/2″F
	7	102	49-345	2.92-20.68	103-731	110	150	76	1222	1537
	9.5	138	59-309	3.52-18.52	124-654	110	150	76	1222	1537
	12.5	181	71-268	4.23-16.08	150-568	110	150	76	1222	1537
